C# .Net Core Console Ascii Ağaç Yapısı Oluşturma

Merhabalar;

C# .Net Core uygulamasında konsol da ağaç yapısında bir listelemeye ihtiyacım oldu.

Andrew Lock’un bloğunda bu konuda bir örneğe rastladım, kodları aşağıda görebilirsiniz, ayrıca Github adresimdem proje dosyalarına ulaşabilirsiniz.

Kod örneğimizde program.cs ve node.cs içeriklerimizi paylaşalım.

Program.cs

using System;
using System.Collections.Generic;
using System.Diagnostics;

namespace AsciiTreeDiagram
{
    class Program
    {
        // Constants for drawing lines and spaces
        private const string _cross = " ├─";
        private const string _corner = " └─";
        private const string _vertical = " │ ";
        private const string _space = "   ";

        static void Main(string[] args)
        {
            // Get the list of nodes
            List<Node> topLevelNodes = CreateNodeList();

            foreach (var node in topLevelNodes)
            {
                PrintNode(node, indent: "");
            }

            if (Debugger.IsAttached)
            {
                Console.WriteLine("Press any key to exit...");
                Console.Read();
            }
        }

        static void PrintNode(Node node, string indent)
        {
            Console.WriteLine(node.Name);

            // Loop through the children recursively, passing in the
            // indent, and the isLast parameter
            var numberOfChildren = node.Children.Count;
            for (var i = 0; i < numberOfChildren; i++)
            {
                var child = node.Children[i];
                var isLast = (i == (numberOfChildren - 1));
                PrintChildNode(child, indent, isLast);
            }
        }

        static void PrintChildNode(Node node, string indent, bool isLast)
        {
            // Print the provided pipes/spaces indent
            Console.Write(indent);

            // Depending if this node is a last child, print the
            // corner or cross, and calculate the indent that will
            // be passed to its children
            if (isLast)
            {
                Console.Write(_corner);
                indent += _space;
            }
            else
            {
                Console.Write(_cross);
                indent += _vertical;
            }

            PrintNode(node, indent);
        }

        static void PrintNodeIncorrectly(Node node, int depth, bool isFirstChild, bool isLastChild, bool parentIsLastChild)
        {
            // something
        }

        static void PrintNodeButMakeHardWorkOfIt(Node node, bool isFirstChild, bool isLastChild, Node[] parentNodes)
        {
            // implementation
        }

        static List<Node> CreateNodeList()
        {
            return new List<Node>
            {
                new Node
                {
                    Name = "Default",
                    Children =
                    {
                        new Node
                        {
                            Name = "Package",
                            Children = {
                                new Node
                                {
                                    Name = "Zip-Files",
                                    Children = {
                                        new Node
                                        {
                                            Name = "Copy-Files",
                                            Children = {
                                                new Node
                                                {
                                                    Name = "Run-Unit-Tests",
                                                    Children = {
                                                        new Node
                                                        {
                                                            Name = "Build",
                                                            Children = {
                                                                new Node
                                                                {
                                                                    Name = "Restore-NuGet-Packages",
                                                                    Children = {
                                                                        new Node { Name = "Clean" }
                                                                    }
                                                                }
                                                            }
                                                        }
                                                    }
                                                }
                                            }
                                        }
                                    }
                                },

                                new Node
                                {
                                    Name = "Create-Nuget-Packages",
                                    Children = {
                                        new Node
                                        {
                                            Name = "Copy-Files",
                                            Children = {
                                                new Node
                                                {
                                                    Name = "Run-Unit-Tests",
                                                    Children = {
                                                        new Node
                                                        {
                                                            Name = "Build",
                                                            Children = {
                                                                new Node
                                                                {
                                                                    Name = "Restore-NuGet-Packages",
                                                                    Children = {
                                                                        new Node { Name = "Clean" }
                                                                    }
                                                                }
                                                            }
                                                        }
                                                    }
                                                }
                                            }
                                        }
                                    }
                                }
                            }
                        }
                    }
                },

                new Node
                {
                    Name = "AppVeyor",
                    Children =
                    {
                        new Node
                        {
                            Name = "Upload-AppVeyor-Artifacts",
                            Children = {
                                new Node
                                {
                                    Name = "Sign-Binaries",
                                    Children = {
                                        new Node
                                        {
                                            Name = "Zip-Files",
                                            Children = {
                                                new Node
                                                {
                                                    Name = "Run-Unit-Tests",
                                                    Children = {
                                                        new Node
                                                        {
                                                            Name = "Build",
                                                            Children = {
                                                                new Node
                                                                {
                                                                    Name = "Restore-NuGet-Packages",
                                                                    Children = {
                                                                        new Node { Name = "Clean" }
                                                                    }
                                                                }
                                                            }
                                                        }
                                                    }
                                                }
                                            }
                                        }
                                    }
                                },

                                new Node
                                {
                                    Name = "Create-Nuget-Packages",
                                    Children = {
                                        new Node
                                        {
                                            Name = "Copy-Files",
                                            Children = {
                                                new Node
                                                {
                                                    Name = "Run-Unit-Tests",
                                                    Children = {
                                                        new Node
                                                        {
                                                            Name = "Build",
                                                            Children = {
                                                                new Node
                                                                {
                                                                    Name = "Restore-NuGet-Packages",
                                                                    Children = {
                                                                        new Node { Name = "Clean" }
                                                                    }
                                                                }
                                                            }
                                                        }
                                                    }
                                                }
                                            }
                                        }
                                    }
                                }
                            }
                        }
                    }
                }
            };
        }
    }
}

node.cs

using System.Collections.Generic;

namespace AsciiTreeDiagram
{
    class Node
    {
        public string Name { get; set; }

        public List<Node> Children { get; } = new List<Node>();
    }
}
